Our engineers work with you to provide the optimal product of the highest quality for orders of every size. Whether you need standard or a special cable assembly, we can assist you from inception to completion. Let our Sales Team help you out today.
| To Fit Cable Dia. | Cont. Cable Part No. |
Weight Per 100 Pcs. (Lbs.) |
|---|---|---|
| 1/16" - 3/32" | 8012-02 | 4 |
| 1/8" - 5/32" | 8012-04 | 5 |
| 3/16" - 7/32" | 8012-06 | 6 |
| 1/4" - 9/32" | 8012-08 | 12 |
| 5/16" | 8012-10 | 14 |
| 3/8" | 8012-12 | 22 |
| 1/2" | 8012-16 | 36 |
Type 304 Stainless Steel
| To Fit Cable Dia. | Cont. Cable Part No. |
Weight Per 100 Pcs. (Lbs.) |
|---|---|---|
| 1/16" - 3/32" | 8111-02 | 1.7 |
| 1/8" - 5/32" | 8111-04 | 3.4 |
| 5/32" - 3/16" | 8111-06 | 3.4 |
| 1/4" | 8111-08 | 11.7 |
| 5/16" | 8111-10 | 13.0 |
| 3/8" | 8111-12 | 24.2 |
| 1/2" | 8111-16 | 39.5 |
With a variety of hydraulic swagers and rotary swaging machines, we are capable of swaging 3/64” through 1” diameter fittings.
Drop Forged
| To Fit Cable Dia. | Cont. Cable Part No. |
Weight Per 100 Pcs. (Lbs.) |
|---|---|---|
| 1/8" | 8004-04 | 6 |
| 3/16" | 8004-06 | 10 |
| 1/4" | 8004-08 | 19 |
| 5/16" | 8004-10 | 28 |
| 3/8" | 8004-12 | 48 |
| 7/16" | 8004-14 | 78 |
| 1/2" | 8004-16 | 80 |
MIL-DTL-83420
